How to Install a Plug & Play Pan Tail Light on a Triumph Scrambler 1200 (2019–2025)
Introduction
At British Customs, we know your Triumph Scrambler 1200 is more than a motorcycle—it's a reflection of your style. Our Plug & Play Pan Tail Light Kit is designed to simplify customization while upgrading the look and function of your tail section. This step-by-step guide shows you how to install it on Scrambler 1200 models, including XC, XE, and X variants.
Watch the Installation Video
Compatible Part Numbers
- Plug & Play Pan Tail Light for Triumph Scrambler 1200 (2016+)
Motorcycle Compatibility
- 2024–2025 Triumph Scrambler 1200 X
- 2019–2025 Triumph Scrambler 1200 XC
- 2019–2025 Triumph Scrambler 1200 XE
Tools You’ll Need
- 5mm, 4mm, and 6mm Allen hex bits
- T30 Torx bit
- 8mm, 10mm, and 13mm socket/wrench
- Hacksaw, Dremel, or bandsaw (if trimming the fender is needed)
Installation Steps
1. Remove the Seat & Top Tray
- Remove seat.
- Use 5mm Allen to remove the 3 screws on the top tray.
- Lift the tray and free the wiring harness.
2. Detach Stock Tail Light
- Use an 8mm socket to remove tail light screws.
- Remove the assembly and trim fender if necessary.
3. Prepare & Mount New Tail Light
- Run the plug through the fender hole.
- Mount the new light and bracket with included washers and nuts.
4. Reconnect Wiring & Reassemble Fender
- Secure the bracket hand-tightened first.
- Plug in tail and license plate light.
5. Optional: Install British Customs Turn Signals
- Remove stock hardware and install BC signals using 13mm wrench.
- Connect wires: black with red tape to signal harness; verify polarity.
6. Final Check
- Ensure wires are tucked neatly.
- Reinstall top tray and seat.
- Test brake, tail, and turn lights.
Troubleshooting
Need help? Contact us at support@british-customs.com or call +1 (877) 999-BRIT. Our live chat is also available Monday–Friday, 8AM–5PM PST.
Frequently Asked Questions
Which Triumph Scrambler 1200 models are compatible with this tail light kit?
This Plug & Play Pan Tail Light kit is compatible with Triumph Scrambler 1200 models from 2019 to 2025, including the XC, XE, and X variants.
Do I need to cut the fender to install this kit?
Trimming the fender is only necessary if your motorcycle has been previously modified. In most cases, this kit installs without cutting.
Can I use stock turn signals with this tail light?
Stock turn signals are not supported with this kit. We recommend installing British Customs turn signals for full compatibility.
What tools do I need for installation?
You'll need common tools including Allen hex bits (4mm–6mm), T30 Torx bit, 8mm–13mm sockets, and optionally a hacksaw or Dremel.
Is this a plug-and-play installation?
Yes, this is a true plug-and-play kit designed for easy installation with minimal wiring. All connectors and brackets are included.
