How to Remove Factory Mid Pipe Speed Twin

Triumph Speed Twin British Customs Install

HOW TO REMOVE MIDPIPE - LEFT SIDE

1 - Using a 5mm Allen remove the (1) bolt that secures the heat shield to the Midpipe.  Save the (1) heat shield, (1)bolt and (1) clamp for installation.

British Customs Speed Twin Mid Pipe Triumph Removal

British Customs Speed Twin Mid Pipe Triumph Removal

2 - Using a 10mm wrench, loosen the exhaust clamp that secures the mid-pipe to the catalytic converter.

British Customs Speed Twin Mid Pipe Triumph Removal

3 - Using a 12mm socket remove the mounting (1) bolt that secures the mid-pipe to the frame.

British Customs Speed Twin Mid Pipe Triumph Removal

4 - Position the kickstand in the down position and remove the mid-pipe.  Pull the mid-pipe away from the bike to remove.

https://www.youtube.com/watch?v=w7JthgTMHDU

https://www.youtube.com/watch?v=w7JthgTMHDU

HOW TO REMOVE MID PIPE - RIGHT SIDE

1 - Using 5mm Allen remove the (1) bolt that secures the heat shield to the mid-pipe.  Save the (1) heat shield, (1) bolt, and (1) clamp for installation.

British Customs Speed Twin Mid Pipe Triumph Removal

British Customs Speed Twin Mid Pipe Triumph Removal

2 - Using a 10mm wrench, loosen the exhaust clamp

British Customs Speed Twin Mid Pipe Triumph Removal

3 - Using a 12 mm socket and 12mm wrench remove the Midpipe mounting bolt.

British Customs Speed Twin Mid Pipe Triumph Removal

4 - Remove the Midpipe by pulling away from the bike and sliding the heat shield backward

British Customs Speed Twin Mid Pipe Triumph Removal

British Customs Speed Twin Mid Pipe Triumph Removal

British Customs Speed Twin Mid Pipe Triumph Removal
